ROTOR DISC » RN2748V

Image Not Available

Specification

Type
Vented
Outter Ø
270
Num. of holes
5
Hole Ø:
M10
Disc Thickness (Max)
24.5
Disc Thickness (Min)
22
Height
42.8
Centering Diameter
82
Pitch Circle Ø
103.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

JAC
3103102-R002LJ
JAC
3501030-R002
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

JAC   »   Sunray

10.16~ 2700 HFC4DE1-1D LC6T32 RN2748V PN6006PN0275 PN6007FN0543
