ROTOR DISC » RN2721V

RN2721V

Specification

Type
Vented
Outter Ø
231
Num. of holes
4
Hole Ø:
12.7
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
49.1
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
125
Front/Rear
Front
Structure Material
G3000

Cross Reference

SUZUKI
55311-84M00
SUZUKI
55311-84M00-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Celerio

03.14~ 1000 K10B LF RN2721V PN9443 FN9804
