ROTOR DISC » RN1985

Specification

Type
Solid
Outter Ø
211
Num. of holes
4
Disc Thickness (Max)
11
Height
43.7
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
125
Disc Thickness (Min)
10
Front/Rear
Front
Structure Material
G3000
Hole Ø:
12.7

Cross Reference

MAZDA
1A06-33-251
MAZDA
1A06-33-251A
MAZDA
1A09-33-251
MAZDA
1A15-33-251
NISSAN
40206-4A00B
NISSAN
40206-4A00J
NISSAN
40206-4A00K
NISSAN
40206-4A00L
NISSAN
40206-4A0A4
SUZUKI
55311-72J10
SUZUKI
55311-72J11
SUZUKI
55311-72J20
SUZUKI
55311-81M10
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.04~08.07 660 K6A HB24S RN1985RN1986 PN9426PN9523 FN9967
12.09~12.14 660 K6A HB25S RN1985 PN9523 FN9967
02.06~02.11 660 K6A# MG22S RN1787VRN1985 PN9523 FN9967
02.11~05.16 660 R06A# MG33S RN1985 PN9523 FN9967FN9999
01.07~11.09 660 K6A HC24S RN1985 PN9523 FN9967
04.04~12.09 660 K6A HA24S RN1986RN1985 PN9523PN9426 FN9967
11.05~12.09 660 K6A HA24V RN1985 PN9523 FN9967
12.09~12.14 660 K6A HA25S RN1985 PN9523 FN9967
12.09~12.14 660 K6A HA25V RN1985 PN9523 FN9967
01.02~02.09 660 K6A# HE21S RN1787VRN1985 PN9523PN9426 FN9967FN9959
09.08~06.15 660 K6A# HE22S RN1985 PN9523 FN9967
11.06~01.11 660 K6A# HG21S RN1985RN2015V PN9523 FN9967
01.05~12.10 660 K6A# MF22S RN1787VRN1985 PN9523 FN9967
01.11~03.16 660 R06A# MF33S RN1985 PN9523 FN9967FN9999
09.03~09.08 660 K6A# MH21S RN1985 PN9426PN9523 FN9967
01.07~10.08 660 K6A# MH22S RN1985RN2015V PN9523 FN9967
09.08~08.12 660 K6A# MH23S RN1985 PN9523 FN9967

Exemption from liability: the catalog data is advisory and can be used for reference only
