ROTOR DISC » RN1954V

RN1954V

Specification

Type
Vented
Outter Ø
254
Num. of holes
4
Disc Thickness (Max)
22
Height
42
Centering Diameter
55
Pitch Circle Ø
100
Drum Ø:
137
Front/Rear
Front
Structure Material
G3000

Cross Reference

DAIHATSU
43512-B1030
DAIHATSU
43512-B1031
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DAIHATSU   »   Boon

06.04~02.10 1300 K3-VE M301S RN1481VRN1954V PN6492PN5544 FN2397FN0042

DAIHATSU   »   Materia

05.06~01.13 1300 K3-VE M401L RN1954V PN5562 FN2397
09.06~08.09 1500 3SZ-VE M402 LHD GCC RN1954V PN5562 DN1433 FN2397
09.06~08.09 1500 3SZ-VE M402S SG RHD RN1954V PN5562 FN2397

DAIHATSU   »   Sirion

06.07~01.13 1300 K3-VE M301L RN1954V PN5544PN6492 DN1433 FN2397
06.07~01.13 1500 3SZ-VE M303 RN1954V PN5544 DN1433 FN2397
01.05~01.13 1500 3SZ-VE M303S RN1954VRN1481V PN6492PN5562 FN2397

PERODUA   »   Myvi

05.05~06.11 1300 K3-VE M301 RN1462VRN1481VRN1954V PN9443PN5562 FN0037FN0029
06.11~11.17 1300 K3-VE M600 RN1954VRN1462VRN1481V PN9443PN5562 FN0029FN0037
