NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1921V

Product
Application

ROTOR DISC » RN1921V

Specification

Type

Vented

Outter Ø

257

Num. of holes

4

Disc Thickness (Max)

17

Height

49.2

Centering Diameter

60

Pitch Circle Ø

100

Drum Ø:

151

Front/Rear

Front

Structure Material

G3000

Cross Reference

SUZUKI

55311-80G02

SUZUKI

55311-80G03

SUZUKI

5531180G00

SUZUKI

5531180G01

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUZUKI » Alto

12.00~01.05

660

K6A

HA23V

RN1921V

PN9426

FN9959 FN9967

SUZUKI » Chevrolet Cruze

10.01~11.03	1300	M13A	HR51S	RN1921V	PN9443		FN9959
11.01~06.08	1300	M13A	HR52S	RN1921V	PN9443		FN9959
10.01~11.03	1500	M15A	HR81S	RN1921V	PN9443		FN9959
11.03~06.08	1500	M15A	HR82S	RN1921V	PN9443		FN9959

SUZUKI » Ignis

06.00~01.08	1300	M13A	FHX51	RN1921V	PN9443		FN9959
06.00~01.08	1300	M13A	FHY51	RN1921V	PN9443		FN9959
06.03~01.08	1500	M15A	FHV81	RN1921V	PN9443		PN9800

SUZUKI » Kei

10.98~04.01	660	F6A#	HN11S	RN1921V	PN9426		FN9959
04.01~11.01	660	F6A#	HN12S	RN1921V	PN9426		FN9959 PN8206
03.01~10.09	660	K6A	HN22S	RN1921V RN1986	PN9426 PN9443		FN9967 PN8206 FN9959
09.98~04.01	660	K6A#	HN21S	RN1921V RN1986	PN9443 PN9426		FN9959

SUZUKI » Swift

01.00~11.04	1300	M13A	HT51S	RN1921V	PN9443		PN9800 FN9959
06.03~11.04	1500	M15A	HT81S	RN1921V	PN9443		PN9800
