ROTOR DISC » RN1560V

Specification

Type
Vented
Outter Ø
256
Num. of holes
4
Disc Thickness (Max)
24
Height
45.5
Centering Diameter
60
Pitch Circle Ø
100
Front/Rear
Front
Drum Ø:
125
Disc Thickness (Min)
21
Structure Material
G3000

Cross Reference

GM
13502001
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.11~10.15 1200 A12XER / LDC 1JC48 RHD HB RN1560V PN0632 DN1685 FN0727
09.11~10.15 1200 A12XER / LDC 1JG48 LHD HB RN1560V PN0632 DN1685 FN0727
10.11~10.15 1300 LDV / A13DTC 5DR HB EL RN34001VRN1560V PN0391PN0632 DN1684 FN11174FN0760
10.11~10.15 1400 A14XER / LDD 1HJ69 RN1560V PN0632 DN1685 FN0727
10.11~10.15 1600 F16D4 / LDE 1J_ HB RN1560V PN0632 DN1685 FN0727
01.13~01.19 1500 L2C 1JX69 UZ RU RN1560V PN0632PN0627 DN1685 FN0727
05.17~ 1800 LSJ LT RN1560VRN2491V PN0632PN0627PN0957 DN1685 FN0727
01.14~03.19 1400 A14XER TA48 RN34001VRN1560V PN0632PN0391 DN1685DN1684 FN0727FN0760
06.11~12.17 1400 A14XER TA69 RN1560VRN34001V PN0632PN0391 DN1685DN1684 FN0727PN0392
08.11~01.17 1400 A14XER / LDD 1J#69 SDN RHD RN1560V PN0632 DN1685 FN0727
08.11~01.17 1600 F16D4 / LDE 1JD69 SDN LHD RN1560V PN0632 DN1685 FN0727
06.12~ 1200 A12XER / LDC MPV RN1560V PN0632 FN0760
02.13~07.15 1300 LDV / A13DTC 1KJ75 RN1560V PN0632 DN1878 FN0760
03.13~ 1300 Z13DTJ MPV RN1560V PN0632 FN0760
02.13~07.15 1500 L2B 1KJ75 RN1560V PN0632 DN1878 FN0760
01.17~ 1800 N18XFH MPV RN1560V PN0632PN0957 FN0760
12.16~ 1500 B15D2 R4 RN1560V PN0632 DN1685 FN0727

Exemption from liability: the catalog data is advisory and can be used for reference only
