NiBK Brakes:: Application Cross Reference and Image for NiBK : BRAKE SHOE : FN9807

Product
Application

BRAKE SHOE » FN9807

Specification

Radius

99,5

Width

27

Thickness

6.5

Pcs In Set

4

Cross Reference

SUZUKI

53200M74L00

SUZUKI

53200M74L00000

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MARUTI SUZUKI » CIAZ

11.14~	1300	D13A		RN1787V	PN9529		FN9807
09.15~	1300	D13A		RN1787V	PN9529		FN9807

MARUTI SUZUKI » SWIFT

08.11~02.18	1200	K12M	ZF62S	RN1787V	PN9529		FN9807
08.11~	1300	D13A		RN1787V	PN9529		FN9807

MARUTI SUZUKI » SWIFT DZIRE

02.12~	1200	K12M		RN1787V	PN9529		FN9807
02.12~	1300	D13A		RN1787V	PN9529		FN9807

SUZUKI » Ciaz

09.14~	1400	K14B	AVB414	RN2245V RN1787V	PN9529		FN9991 FN9807
08.18~	1500	K15B	AVB415-2 LHD	RN1787V			FN9807

SUZUKI » Dzire

05.17~

1200

K12M

RN1787V

PN9529

FN9807

SUZUKI » Swift IV

08.11~01.14	1200	K12M	ZC62S HB LHD	RN1787V	PN9529		FN9807
08.11~02.18	1200	K12MN	AZI412 SDN	RN1787V	PN9529		FN9807
02.13~02.18	1200	K12MN	AZI412 SDN TYPE 2 RHD	RN1787V	PN9529		FN9807
10.13~05.18	1200	K12MN	ZC62S HB LHD	RN1787V	PN9529		FN9807
08.11~02.18	1200	K12MN	ZC62S HB RHD	RN1787V	PN9529		FN9807
08.11~02.18	1200	K12MN	ZC62S HB RHD	RN1787V	PN9529		FN9807
08.11~01.15	1200	K12MN	ZF62S SDN RHD	RN1787V	PN9529		FN9807
01.15~02.18	1200	K12MN	ZF62S SDN RHD	RN1787V	PN9529		FN9807
