NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1206V

Menu

ROTOR DISC » RN1206V

RN1206V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
6
Height
41
Centering Diameter
59
Pitch Circle Ø
100
Front/Rear
Front
Outter Ø
236
Drum Ø:
123
Disc Thickness (Min)
18
Structure Material
G3000

Cross Reference

CHEVROLET
96471274
CHEVROLET
96574633
DAEWOO
96574633
GM
09056028
GM
9056028
GM
96471274
GM
96574632
GM
96574633
HI-Q
SD3001
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHEVROLET (GM)   »   Aveo (T200)

01.05~01.08 1400 F14D3 / L14 3DR HB CH RN1206V PN0370 DN1680 FN11174
03.02~01.08 1400 F14D3 / L14 SA48 5DR HB RN1206V PN0370PN0374 DN1668 FN11174
03.02~01.08 1400 F14D3 / L14 SDN CHL RN1206V PN0374PN0370 DN1668 FN11174
03.02~02.08 1500 F15S3 / LX6 SA48 5DR HB RHD RN1206V PN0370 DN1668DN1680 FN11174
03.02~02.08 1500 F15S3 / LX6 SF69 RN1206V PN0370 DN1680DN1668 FN11174

CHEVROLET (GM)   »   Aveo (T250)

03.05~01.12 1400 F14D3 / L14 SA69 GEN RN1206V PN0370 DN1680 FN11174
03.05~01.12 1400 F14D3 / L14 SF48 RN1206V PN0370PN0374 DN1680 FN11174
03.05~01.12 1400 F14D3 / L14 SF69 RN1206VRN2117V PN0370PN0374 DN1680 FN11174
12.07~01.12 1400 F14D3 / L95 SA69 EUR RN1206V PN0370 DN1680 FN11174
12.07~01.12 1400 F14D3 / L95 SA69 GEN SDN RN1206V PN0370 DN1680 FN11174

CHEVROLET (GM)   »   Aveo (T250/T255)

01.08~01.12 1200 B12D1 / LMU SDN LHD RN1206V PN0370 DN1680 FN11174
12.07~01.13 1400 F14D3 / L95 SA48 RN1206V PN0374PN0370 DN1680 FN11174
12.07~01.13 1400 F14D3 / L95 TJ63 HB LHD RN1206V PN0370 DN1680 FN11174
12.07~01.13 1400 F14D4 / LDT HB CHL RN1206V PN0370PN0374 DN1680 FN11174
12.07~01.12 1400 F14D4 / LDT SF69 SDN EU RN1206V PN0370 DN1680 FN11174
01.08~01.13 1500 F15S R69 RN1206VRN2117V PN0374PN0370 DN1680 FN11174
01.08~01.13 1500 F15S3 / LX6 SA48 HB LHD RN1206V PN0374PN0370 DN1680 FN11174
01.08~01.13 1500 F15S3 / LX6 TM63 HB RHD RN2117VRN1206V PN0370PN0374 DN1680 FN11174
01.08~01.13 1500 LV8 SDN VTN RN1206V PN0374PN0370 DN1680 FN11174

CHEVROLET (GM)   »   Kalos

07.03~05.08 1400 F14D3 / L14 SA69 RN1206V PN0370 FN11174

CHEVROLET (GM)   »   Kalos (T250) Sedan

05.05~12.08 1200 F12S T250 RN1206V PN0370 FN11174
05.05~12.08 1400 F14# T250 RN1206V PN0370 FN11174

CHEVROLET (GM)   »   Sail

01.10~01.15 1400 LCU SGM RN1206V PN0572 FN0790

CHEVROLET (GM)   »   Spark

01.10~01.17 800 F8CV HB LITE RN1206VRN1546 PN0390 DN1688 FN11821
05.07~01.19 800 LBF / A08S3 KA48 SG RHD RN1546RN1206V PN0390 DN1688 FN11821
01.05~01.10 1000 B10S1 KF48 RHD RN1206VRN1546 PN0390 DN1688 FN11821
01.13~01.16 1000 LFM / B10D2 RCE48 LHD RN1206V PN0570 DN1680
01.10~01.16 1000 LMT / B10D1 1C#48 RN1206V PN0570 DN1680 FN11174
01.10~01.13 1000 LMT / B10D1 MA48 KR RN1206V PN0570 DN1680 FN11174
01.10~01.13 1000 LMT / B10D1 MA48 SG RN1206V PN0570 DN1680 FN11174
01.11~01.21 1200 B12D1 / LMU 1C#48 LHD RN1206V PN0570 DN1680 FN11174
10.10~01.16 1200 B12D1 / LMU 1C#48 RHD RN1206V PN0570 DN1680 FN11174

DAEWOO   »   Matiz

05.05~01.10 800 F8CV HB VTN RN1206VRN1546 PN0390 DN1688 FN11821

DAEWOO   »   Matiz III

01.10~12.15 1000 LMT / B10D1 RC#48 RN1206V PN0570 DN1680 FN11174

KIA   »   Carnival / Sedona 06

07.06~12.09 2700 G6EA VQ RN1206V PN0458PN0588 PN0457

RAVON   »   R2

02.16~ 1200 B12D2 R2 RN1206V PN0570 DN1680 FN11174

SUZUKI   »   Swift +

01.08~01.12 1600 F16D4 TJ6D RN2117VRN1206V PN0374PN0370 DN1680 FN11174
