ROTOR DISC » RN1030V

Specification

Type
Vented
Disc Thickness (Max)
23
Num. of holes
4
Height
34
Centering Diameter
92
Front/Rear
Front
Outter Ø
259.6
Pitch Circle Ø
114.3
Disc Thickness (Min)
21
Drum Ø:
160
Structure Material
G3000

Cross Reference

BENDIX
561671B
HONDA
45251-SM4-020
HONDA
45251SM4000
HONDA
45251SM4010
HONDA
45251SN7E40
ROVER
GBD90836
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.89~09.93 1800 F18A CB1 RN1030V PN8223 RN1054 PN8398FN5520
02.96~01.98 1800 F18A# CE7 EU RN1030V PN8293PN8254 RN1054 PN8398
01.94~12.96 1800 F18A/3/4 EURO RN1030V PN8293PN8254 RN1054 PN8398
10.93~09.97 1800 F18B CD3 RN1030V PN8223 RN1054 FN5520PN8398
01.96~12.97 1800 F18B EURO RN1030V PN8223 RN1054 FN5520PN8398
01.99~12.00 2000 20T2N EURO RN1030V PN8293 RN1054 PN8398
01.96~12.98 2000 20T2N# CF1 EU RN1030V PN8293 RN1054 PN8398
01.96~12.96 2000 20T2N14/15 EURO RN1030V PN8293 RN1054 PN8398
09.89~09.93 2000 F20 CB4 RN1030V PN8223 RN2071 PN8398
09.89~09.93 2000 F20A CB3 RN1030V PN8223 RN1054 PN8398
04.90~02.94 2000 F20A1/3/8 EURO RN1030V PN8484 RN1054 PN8398FN5524
09.93~09.97 2000 F20B CD4 JPN RN1030V PN8223 RN1054 PN8398FN5520
09.93~09.97 2000 F20B CD4 RHD RN1030V PN8223PN8484 RN1054 PN8398FN5520
01.93~12.98 2000 F20B1 EURO RN1030V PN8484 RN1054 PN8398FN5524
02.93~09.98 2000 F20Z1/2 CC7 EU RN1030V PN8293 RN1054 PN8398
01.93~12.96 2000 F20Z1/2 EURO RN1030V PN8254PN8293 RN1054 PN8398
01.92~02.94 2200 F22A CB7 RN1030V PN8223PN8814 RN1054 PN8398
01.90~12.93 2200 F22A EURO RN1030V PN8484PN8814 RN1054 PN8398FN5524
09.89~08.93 2200 F22A3 CB7 RN1030V PN8223PN8814 RN2071DN1387 PN8398FN5524
10.94~12.98 2200 F22B1 CD5 RHD RN1030V PN8484 RN1054 PN8398
01.94~12.97 2200 F22B1-5 EURO RN1030V PN8223 RN1054 PN8398FN5524
01.96~12.97 2200 F22Z4 EURO RN1030V PN8484PN8254 RN1054 PN8398
08.93~12.98 2200 F22B CD9 US RN1030V PN8484PN8254 RN1054 PN8398
08.93~12.98 2200 F22B2 EURO RN1030V PN8254PN8484 RN1054 PN8398
09.89~02.95 2000 G20A CB5 RN1030V PN8223 RN1054 PN8398
02.94~09.97 2200 F22B CE1 RN1030V PN8484 RN1054 PN8398
09.89~10.93 1800 F18A CB1 RN1030V PN8223 RN1054 FN5520PN8398
02.92~10.97 2300 H23A CC5 RN1030V PN8223 RN2071 PN8398
10.93~03.98 2000 G20A CE4 RN1030V PN8223 RN1054 PN8398FN5524
03.96~01.01 1600 D16Y# EK1 RN1030VRN1089V PN8264 RN1047 FN5520PN8206
09.89~02.95 2000 G20A CB5 RN1030V PN8223 RN1054 PN8398
03.96~06.99 2000 20T2R RN1030V PN8293 RN1054 PN8398

Exemption from liability: the catalog data is advisory and can be used for reference only
