ROTOR DISC » RN1024V

Specification

Type
Vented
Disc Thickness (Max)
17
Num. of holes
4
Height
44.2
Centering Diameter
61
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
230.8
Disc Thickness (Min)
15
Drum Ø:
123
Structure Material
G3000

Cross Reference

HONDA
45251SA2751
HONDA
45251SB2750
HONDA
45251SB2751
HONDA
45251SB2752
HONDA
45251SB2920
HONDA
45251SB2930
HONDA
45251SB2931
HONDA
45251SB2932
HONDA
45251SB2940
ROVER
GBD443
ROVER
GBD90803
ROVER
GBD90814
ROVER
GBD90825
ROVER
XAP88
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.99~01.03 1300 D13B# 3A2 LHD MLY RN1024V PN8263 DN1383 FN5519FN5527
01.97~01.03 1300 D13B# CG RN1024V PN8263 FN5519FN5527
01.96~06.99 1500 B15B9 MRH3A3 RN1024V PN8263 RN1052 PN8206
07.99~10.02 1500 B15C 3A3 RN1024V PN8263 RN1052 PN8206
01.97~01.03 1500 D15B7 CG RN1024V PN8263 FN5527FN5519
01.97~01.99 1800 XUD7T CG RN1024V PN8263 FN5527FN5519
01.91~12.95 1300 D13B EG3 RN1024V PN8263 DN1383 FN5527FN5519
08.95~09.00 1300 D13B EK2 RN1024VRN1375V PN8263PN8265 DN1385DN1383 FN5519FN5527FN5520
07.89~09.91 1400 D14A1 EC9 3DR RN1024V PN8263 DN1383 FN5519FN5527
01.88~12.91 1400 D14A1 ED2 RN1024V PN8263 FN5519FN5527
01.88~12.91 1500 D15B ED3 RN1024V PN8263 FN5519FN5527
06.87~08.91 1500 D15B EF2 RN1024VRN1844 PN8263 FN5519FN5527
09.91~08.95 1500 D15B EG4 (4DR) RN1375VRN1024VRN1089V PN8264PN8265PN8263 RN1047RN1052DN1383 FN5527PN8206FN5519
09.91~08.95 1500 D15B EG4 JPN RN1024VRN1375VRN1089V PN8263PN8265PN8264 DN1383RN1052RN1047 FN5519PN8206FN5527
09.91~08.95 1500 D15B# EG4 RN1375VRN1024V PN8265PN8263 DN1383 FN5519FN5527
10.95~03.99 1500 D15Z# EK3 4DR SDN RN1375VRN1024VRN1089V PN8265PN8264PN8263 RN1052RN1047DN1385 PN8206FN5520FN5519FN5527
11.87~12.91 1400 D14A EE6 RN1024V PN8263 DN1383 FN5527FN5519
08.91~09.95 1300 D13B EG7 RN1024VRN1089V PN8263PN8265 FN5519FN5527
11.99~01.06 1000 ECA-MF2 ZE1 RN1024V PN8804 FN0656
02.86~04.89 1500 EW2 DA2 RN1024V PN8263 DN1383 FN5527FN5519

Exemption from liability: the catalog data is advisory and can be used for reference only
