ROTOR DISC » RN2753

RN2753

Specification

Type
Solid
Outter Ø
296
Num. of holes
5
Disc Thickness (Max)
10
Disc Thickness (Min)
8.5
Height
47.1
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Rear
Structure Material
G3000

Cross Reference

TOYOTA
42431-0D210
TOYOTA
42431-F4051
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   C-HR

10.23~ 1800 2ZR ZYX20 RN2032V PN1858 RN2753 PN1864
10.23~ 2000 M20 MAXH20 RN2032V PN1858 RN2753 PN1864
01.24~ 2000 M20 MAXH21 RN2753 PN1864
10.23~ 2000 M20 MAXH25 RN2753 PN1864

TOYOTA   »   Yaris Cross

07.21~ 1500 M15AFXE MXPJ10L RN2192V PN1863 RN2753 PN1864
