DRUM BRAKE » DN1133

Image Not Available

Specification

Outter Ø
216
Num. of holes
4
Centering Diameter
55
Height
51.5
Pitch Circle Ø
100
Drum Ø
180
Structure Material
G3000

Cross Reference

DAIHATSU
42431-BZ270
TOYOTA
42431-BZ270
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DAIHATSU   »   Ayla

03.23~ 1000 1KR-VE A350RS RN2523V PN6427 DN1133 FN0850
03.23~ 1200 WA-VE A351RS RN2523V PN6427 DN1133 FN0850

TOYOTA   »   Agya/Wigo

03.23~ 1000 1KR-VE A350 RN2523V PN1805PN6427 DN1133 FN0850
03.23~ 1200 WA-VE A351 RN2523V PN6427PN1805 DN1133 FN0850
