PERFORMANCE ROTOR DISC » RN1268DSET

RN1268DSET

Specification

Outter Ø
340
Num. of holes
5
Disc Thickness (Max)
32
Height
83.4
Centering Diameter
112
Pitch Circle Ø
150
Drum Ø:
183
Type 1:
Vented
Disc Thickness (Min)
30
Structure Material
GG20
Front/Rear
Front

Variation

RN1268V[NiBK]

Cross Reference

TOYOTA
43512-60180
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LEXUS   »   LX460

01.12~09.15 4600 1UR-FE URJ202 RN1268V PN1541 RN1267V PN1542 FN0647

LEXUS   »   LX570

11.07~ 5700 3UR-FE URJ201 RN1268V PN1541 RN1267V PN1542 FN0647

TOYOTA   »   Land Cruiser 200

09.07~08.15 4000 1GR-FE GRJ200L RN1268V PN1541 RN1267V PN1542 FN0647
09.07~ 4500 1VD-FTV VDJ200L RN1268VRN22002V PN1541 RN1267V PN1542 FN0647
09.07~ 4500 1VD-FTV VDJ200R RN22002VRN1268V PN1541 RN1267V PN1542 FN0647
05.09~ 4600 1UR-FE URJ202L RN1268V PN1541 RN1267V PN1542 FN0647
04.09~ 4600 1UR-FE URJ202W RN1268V PN1541 RN1267V PN1542 FN0647
09.07~03.12 4700 2UZ-FE GRJ200R RN1268V PN1541 RN1267V PN1542 FN0647
09.07~01.12 4700 2UZ-FE UZJ200L RN1268V PN1541 RN1267V PN1542 FN0647
09.07~05.09 4700 2UZ-FE UZJ200W RN1268V PN1541 RN1267V PN1542 FN0647
09.07~08.15 5700 3UR-FE URJ200L RN1268V PN1541 RN1267V PN1542 FN0647
